41/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
7.7 Measurement transmission
In Profibus DPV1 communication protocol, measurements (except for tare value) can be included in the cyclic input
frame. The modular slave structure allows the user to select the variables according to his needs. These data cannot
be accessed through acyclic requests.
7.8 EEPROM error management
Functioning and calibration parameters are stored in EEPROM NOV RAM. After every reset the entireness of
parameters stored in EEPROM is checked. If a default appears, measurements are set to 0xFFFF and default is pointed
out into module 1 and bit b
4
of extended diagnoses register.
