bits
meaning
note
b
12
(or b
4
in CANopen®)
set point 4 commutation mode
0
window
only if output 4 assigned to the ‘set point’
function
1
hysteresis
b
14
b
13
(or b
6
b
5
in CANopen®)
set point 4 comparison measurement
00
gross
01
net
10
Sensor input control result
11
Batch
b
15
(or b
7
in CANopen®)
reserved (0)
13.2.9 Set points high and low values
Each set point is described by its commutation mode (hysteresis/window) and by a couple of values that are
constantly compared to the gross or net measurement or to dosing result or dosing running total (depending on the
configuration the set point has been given) in order to define the corresponding output logical level. For more details
about the set points functioning, please refer to documentation ref. 236722.
Admitted values: from -1000000 to 1000000.
