bits
Meaning
Note
1
otherwise
b
8
0
IN1 logical level
1
b
9
0
IN2 logical level
1
b
10
0
OUT1 logical level
1
b
11
0
OUT2 logical level
1
b
12
0
OUT3 logical level
1
b
13
0
OUT4 logical level
1
b
14
0
no tare
1
at least a tare has been processed
b
15
0
reserved
1 in SCMBus and fast SCMBus, 0
otherwise
1
Note 1: Functioning and calibration parameters are stored in EEPROM. After every reset the entireness of parameters
stored in EEPROM is checked. If a defect appears, measurements are set to 0xFFFF and defect is pointed out in
measurement status. Causes a logical output assigned to the ‘defective measurement’ function to be set active.
Causes the analog output assigned to a weight or flow rate image to be set in error mode.
9.2 Weighing diagnosis
9.2.1 Global weighing diagnosis
An internal alarm flag reflects the integrity of the whole measurement chain. It’s used to set logical output active or
optional analog output in an error mode in order to warn about any defection on the measurement chain (defective
measurement).
