Scaime eNod4-B - Logical Outputs 3&4 Assignment; Weight Quantity Per Pulse on Logical Output

72/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
bits
meaning
note
0111
external totalizer
Belt mode
1000
belt system running
Belt mode
1001
batch in progress
Belt mode
1010
batch result available
Belt mode
1011
conveyor starting alarm
Belt mode
1100
material TOR gate
Belt mode
b
12
(or b
4
in CANopen®)
output 2 logical
0
negative logic
defines the output level when enabled
1
positive logic
defines the output level when enabled
13.2.6 Logical outputs 3&4 assignment
Similar to the outputs 1&2 configuration parameter, see previous paragraph (replacing all references to output 1 by
output 3 and all references to output 2 by output 4).
13.2.7 Weight quantity per pulse on logical output
When a logical output is assigned to external totalizer, a pulse is generated every time the totalization increases a
multiple of a weight quantity per pulse on logical output. The maximum pulse frequency is 10 Hz and pulse duration
is fixed at 50ms. The output pulse is not rounded (i.e. the pulse is issued only once weight quantity per pulse on
logical output is strictly exceeded).
