13.2.5 Logical outputs 1&2 assignment
The following table describes the possible assignments.
bits
meaning
note
b
3
b
2
b
1
b
0
output 1 assignment
0000
none
the output level does not vary
0001
set point 1
functioning described by the ‘set point functioning’ setting
and by the ‘set point 1 high and low values’
0010
motion
copies the motion flag of the status bytes
0011
defective measurement
reflect the internal alarm flag described in “Weighing
diagnosis” § in the MEASUREMENT AND STATUS §
0100
input 1 image
copies input 1 level
0101
level on request
output 1 level is driven by the ‘OUT1
activation/deactivation’ functional command
0110
belt alarms
Belt mode (alarm flag representing the OR logical
operation between the error bits of the alarms registers
word)
0111
external totalizer
Belt mode
1000
belt system running
Belt mode
1001
batch in progress
Belt mode
1010
batch result available
Belt mode
1011
conveyor starting alarm
Belt mode
1100
material TOR gate
Belt mode
b
4
output 1 logical
0
negative logic
defines the output level when enabled
1
positive logic
b
11
b
10
b
9
b
8
(or b
3
b
2
b
1
b
0
in
CANopen®)
output 2 assignment
0000
none
the output level does not vary
0001
set point 2
functioning described by the ‘set point functioning’ setting
and by the ‘set point 2 high and low values’
0010
motion
copies the motion flag of the status bytes
0011
defective measurement
reflect the internal alarm flag described in “Weighing
diagnosis” § in the MEASUREMENT AND STATUS §
0100
input 2 image
copies input 2 level
0101
level on request
output 2 level is driven by the ‘OUT2
activation/deactivation’ functional command
0110
belt alarms
Belt mode (alarm flag representing the OR logical
operation between the error bits of the alarms registers
word)
