Scaime eNod4-B - Decimal Point Position; Weight Unit

78/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
A/D conversion rate (meas/s)
X
50-Hz rejection
60-Hz rejection
6,25
7,5
1
12,5
15
2
25
30
3
50
60
5
100
120
9
200
240
17
400
480
33
800
960
65
1600
1920
129
14.2.7 Decimal point position
Although eNod4 measurements are integer values it is however possible to store a ‘decimal point position’ so as to
design a display related to the application. Its value represents the number of decimal digits. If the variable is set to
Zero, it means that decimal point is not used.
Note: the decimal point is directly integrated to SCMBus protocol frames (see § SCMBus).
Admitted values: from 0 up to 7.
14.2.8 Weight unit
It is possible to store the display weight unit into the eNod4.
In transmitter mode, weight unit is a combination of 4 characters and there is no automatic calculation to adjust
weight values if modified.
In belt mode, following values are permitted for weight unit parameter:
• gram (g)
• kilogram (kg)
• ton (t)
Note: the unit is directly integrated to SCMBus protocol frames (see § SCMBus).
