Scaime eNod4-B - 16 Modbus Rtu Registers Table

89/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
16 MODBUS RTU REGISTERS TABLE
Chapter
Name
Modbus
Address
Type
Access
Modbus
Firmware revision
0x0000
Uint
RO
Modbus
Node number / baud rate
0x0001
Uint
RO
Legal for trade
Legal for trade version
0x0004 LSB
Byte
RO
Legal for trade
Legal for trade switch
0x0004 MSB
Byte
RW
Legal for trade
Legal for trade counter
0x0005
Byte
RO
Legal for trade
Legal for trade checksum
0x0006
Uint
RO
Legal for trade
Zero functions
0x0007
Uint
RW
Legal for trade
Stability criterion
0x0008 LSB
Byte
RW
Legal for trade
decimal point position
0x0008 MSB
Byte
RW
Legal for trade
Weight unit
0x0009
String
RW
Calibration
Maximum capacity
0x000C
Ulong
RW
Calibration
Number of calibration segments
0x000E
Uint
RW
Calibration
Calibration load 1
0x000F
Ulong
RW
Calibration
Calibration load 2
0x0011
Ulong
RW
Calibration
Calibration load 3
0x0013
Ulong
RW
Calibration
Sensor sensitivity
0x0015
Ulong
RW
Calibration
Scale interval
0x0017
Uint
RW
Calibration
Zero calibration
0x0018
Long
RW
Calibration
Span coefficient 1
0x001A
Float
RW
Calibration
Span coefficient 2
0x001C
Float
RW
Calibration
Span coefficient 3
0x001E
Float
RW
Calibration
Span adjusting coefficient
0x0020
Ulong
RW
Calibration
Calibration place g value
0x0022
Ulong
RW
Calibration
Place of use g value
0x0024
Ulong
RW
Calibration
Number of divisions at maximum capacity
0x0028
Ulong
RW
Calibration
Instant flow rate correction factor
0x002C
Float
RW
I/O
External value to control analog output
0x0032
Uint
RW
HMI
HMI name
0x0034
String
RW
Filter
A/D conversion rate
0x0036
Uint
RW
Filter
filters activation
0x0037 LSB
Byte
RW
Filter
Low-pass order
0x0037 MSB
Byte
RW
Filter
Low-pass cut-off frequency
0x0038
Uint
RW
