Scaime eNod4-B - Page 90

90/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
Chapter
Name
Modbus
Address
Type
Access
Filter
Band-stop high cut-off frequency
0x0039
Uint
RW
Filter
Band-stop low cut-off frequency
0x003A
Uint
RW
Protocol
Functioning mode / Serial protocol
0x003E
Uint
RW
SCMBus
SCMBus transmission period
0x003F
Uint
RW
I/O
Analog output functioning (optional)
0x0040
Uint
RW
I/O
Logical inputs 3 functioning (optional)
0x0041 LSB
Byte
RW
I/O
Logical inputs 4 functioning (optional)
0x0041 MSB
Byte
RW
I/O
Logical input 1 functioning
0x0042 LSB
Byte
RW
I/O
Logical input 2 functioning
0x0042 MSB
Byte
RW
I/O
holding time
0x0043
Uint
RW
I/O
Output 1 functioning
0x0044 LSB
Byte
RW
I/O
Output 2 functioning
0x0044 MSB
Byte
RW
I/O
Output 3 functioning
0x0045 LSB
Byte
RW
I/O
Output 4 functioning
0x0045 MSB
Byte
RW
I/O
Set point 1 high value
0x0046
Long
RW
I/O
Set point 1 low value
0x0048
Long
RW
I/O
Set point 2 high value
0x004A
Long
RW
I/O
Set point 2 low value
0x004C
Long
RW
I/O
Set point 3 high value
0x004E
Long
RW
I/O
Set point 3 low value
0x0050
Long
RW
I/O
Set point 4 high value
0x0052
Long
RW
I/O
Set point 4 low value
0x0054
Long
RW
I/O
1&2 Set points functioning
0x0056 LSB
Byte
RW
I/O
3&4 Set points functioning
0x0056 MSB
Byte
RW
Belt
Weight quantity per pulse on logical output
0x0057
Uint
RW
Filter
Depth of moving average filter on weights
0x0058
Uint
RW
Filter
Average flow rate/Speed determination depth
0x0059
Uint
RW
Belt
Flow rate time unit
0x005A
Uint
RW
Belt
Minimum weight to totalize x100
0x005B
Uint
RW
Belt
Conveyor starting alarm duration
0x005C
Uint
RW
Belt
Conveyor routing material time
0x005D
Uint
RW
Belt
Conveyor speed stabilization time
0x005E
Uint
RW
Belt
Cycle and alarm options
0x005F
Uint
RW
Belt
Nominal flow rate
0x0060
Float
RW
