13.1.3 Logical outputs
Each output can work individually in positive or negative logic
The available functions are:
function
Operating mode
transmitter
Belt scale
Belt weigh feeder
none
●
●
●
set point
●
●
●
motion
●
●
●
defective measurement
●
●
●
input image
●
●
●
level on request
●
●
●
belt alarms
●
●
external totalizer
●
●
belt system running
●
●
batch in progress
●
●
batch result available
●
●
conveyor starting alarm
●
●
material TOR gate
●
●
• None
The output has no function.
• Motion
The output is dedicated to copying the stability flag level.
• Defective measurement
The output level is set when the internal alarm flag described in “Weighing diagnosis” § in the MEASUREMENT AND
STATUS § is activated. This allows to warn about defection of the measurement chain. Flowrate alarms are not
considered as defective measurements.
• Set point
Each output can be assigned to a configurable set point (set point 1 corresponds to output 1, set point 2 to output 2,
set point 3 to output 3 and set point 4 to output 4).
• Input X image
The output is dedicated to copying a logical input level (outputs 1 and 3 correspond to inputs 1 and 3, outputs 2 and 4
correspond to input 2 and 4).
