67/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
• Level on request
The input level is driven by master requests.
• Belt alarms
The output is dedicated to copying alarm flags level. Alarms might be flow rate or belt speed or belt load or control
output level or external totalizer overflow.
• External totalizer
This output is dedicated to deliver pulses for external totalizer device.
If a logical output is assigned to external totalizer function, eNod4 will send a pulse every time totalization result will
reach a multiple of weight value defined in “weight quantity per pulse on logical output” parameter.
• Belt system running
In belt mode, indicates that a totalization function is activated.
• Batch in progress
In batch mode, indicates that a batch cycle is in progress.
• Batch result available
In batch mode, indicates the end of a cycle (batch target is reached).
• Conveyor starting alarm
eNod4 analog output in current or voltage might be used to drive conveyor speed engine through invertor.
So that for security reason a logical output can be assigned to “Conveyor starting alarm” function and the duration is
configured through “conveyor starting alarm duration” parameter.
• Material TOR gate
Depending application, this output is dedicated to open and to close the belt material two states gate.
