9.1.5 Preset Tare value
A previous calculated tare can be restored using this variable.
9.1.6 Measurement status
The measurement status contains information on eNod4 measurement parameters.
The ‘measurement status’ bytes contain information about every measurement processed by eNod4. See the flags
meaning in the table below:
bits
Meaning
Note
b
1
b
0
00
gross measurement
only in SCMBus/fast communication
protocols
not significant otherwise (00)
01
net measurement
10
factory calibrated measurement
11
tare value
b
3
b
2
00
measurement OK
01
Defect: sensor input control result out of
tolerances OR Sensor input control
command in progress OR failed (timeout)
OR Sensor input reference command in
progress
causes a logical output assigned to the
‘defective measurement’ function to be
set active. Causes the analog output
assigned to a weight or flow rate
image to be set in error mode.
10
gross meas.< (- max capacity) OR gross
meas. > (max capacity)
11
analog signal out of the A/D converter input
range
b
4
0
motion
causes an output assigned to the
‘motion’ function to be set active
1
no motion
b
5
0
measurement out of the ¼ of division
1
zero in the ¼ of division
b
6
0
EEPROM OK
See Note 1
1
EEPROM failure
b
7
0
reserved
1 in SCMBus and fast SCMBus, 0
