84/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
15.1 Settings description
• Weight quantity per pulse on logical output: For external totalization purpose, eNod4 sends a pulse on logical
output when the total value reaches multiple of this parameter. When an overflow is occurred on pulses
output an alarm is set.
• Average flow rate/speed determination depth: Defines the samples “n” numbers for moving average filter on
flow rate and belt speed.
• Minimum load to totalize: eNod4 enables totalization when “minimum weight to totalize x100” divided by
“weigh section length” is greater than the minimum load to totalize.
• Conveyor starting alarm duration: For security reason, eNod4 provides buzzer function on logical output at
belt start. The buzzer duration depends on this parameter value in second.
• Conveyor routing material time: Defines time for materials to travel distance from shear gate to weigh section
at normal speed.
• Conveyor speed stabilization time: In weigh feeder mode and if PID function is done through the belt speed,
this is the stabilization time before PID activation.
• Cycle and alarm options: This register defines cycle and alarms functioning. The table below shows the bits
definitions.
