PID behavior
0x0A3B
0x470C /0x04
R : 0x02E4
W : 0x02E5
0x07 / 0x37
Uint
RW
Reference flow rate for PID adjustment
0x0A3C
0x470C /0x05
R : 0x04E6
W : 0x04E7
0x07 / 0x38
Float
RW
Checked batch
0x0A3E
0x4700 /0x07
R : 0x040C
W : 0x040D
0x07 / 0x3D
Ulong
RW
Belt fault control inhibit time at start
0x0A50
0x4702 /
0x0C
R : 0x02FA
W : 0x02FB
0x0B / 0x01
Uint
RW
Belt fault control inhibit time in service
0x0A51
0x4702 /
0x0D
R : 0x02FC
W : 0x02FD
0x0B / 0x02
Uint
RW
Cut-off frequency for average flow rate (x100)
0x0A52
0x4701 /
0x0A
0x0B / 0x03
Uint
RW
Time unit for average flow rate
0x0A53
0x4701 /
0x0B
0x0B / 0x04
Uint
RW
Weight unit for average flow rate
0x0A54
0x4701 /
0x0C
0x0B / 0x05
Ulong
RW
Instant flow rate
0x0086
0x5005 /0x01
(M)
R: 0x04F4
W: /
+ See modules
list
0xA0 / 0x06
Float
RO
Average flow rate
0x0088
0x5005 /0x02
(M)
See modules
list
/
Float
RO
Average belt speed
0x008A
0x5005 /0x04
(M)
See modules
list
/
Float
RO
Belt alarms registers
0x008C
0x5007 /0x01
(M)
See modules
list
/
Uint
RO
Totalizer value (Great WU)
0x008D
0x5006 /0x01
(M)
R: 0x04F0
W: /
+ See modules
list
0xA0 / 0x04
Ulong
RO
Complementary totalizer value
0x008F
0x5006 /0x02
(M)
R: 0x02F2
W: /
+ See modules
list
0xA0 / 0x05
Uint
RO
Dosing weight deviation
0x0095
0x5007 /0x04
(M)
See modules
list
/
Float
RO
Flow rate control output
0x009A
0x5005 /0x05
(M)
See modules
list
/
Float
RO
Dosing quality factor
0x009C
0x5005 /0x07
(M)
/
/
Float
RO
Errors counter
0x009E
0x5007 /0x03
(M)
See modules
list
/
Uint
RO
Weigh frame load
0x009F
0x5005 /0x03
(M)
R: 0x04F6
W: /
0xA0 / 0x03
Float
RO
Control output value
0x00A1
0x5005 /0x06
(M)
See modules
list
/
Uint
RO
Belt status register
0x00A3
0x5007 /0x02
(M)
See modules
list
/
Uint
RO
Total per belt revolution
0x00A4
0x5006 /0x03
(M)
See modules
list
/
Float
RO
Average flow rate Great Unit
0x00A6
0x5005 /0x08
(M)
/
/
Float
RO
Batch progression in percent
0x00A8
0x5006 /0x04
(M)
See modules
list
/
Uint
RO
Grand total
0x00A9
0x5006 /0x05
(M)
See modules
list
/
Uint
RO
General total
0x00AB
0x5006 /0x06
(M)
See modules
list
/
Uint
RO
