Scaime eNod4-B - Page 82

82/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
Name
Modbus
address
CANopen
index/sub-
index
Profibus Cyclic
IN/OUT
Acyclic
DPV1
slot /
index
Type
Access
Complementary weight to totalize (in weight unit)
0x007A
0x4700 /0x04
R : 0x02A8
W : 0x02A9
0x07 / 0x1A
Uint
RW
Weight to totalize inflight value (in weight unit)
0x007B
0x4700 /0x05
R : 0x04AA
W : 0x04AB
0x07 / 0x1B
long
RW
Calibration point 1 for the control output (output
value)
0x0A00
0x470A /0x01
R : 0x02B4
W : 0x02B5
0x07 / 0x20
Uint
RW
Calibration point 2 for the control output (output
value)
0x0A01
0x470A /0x02
R : 0x02B6
W : 0x02B7
0x07 / 0x21
Uint
RW
Calibration point 3 for the control output (output
value)
0x0A02
0x470A /0x03
R : 0x02B8
W : 0x02B9
0x07 / 0x22
Uint
RW
Calibration point 4 for the control output (output
value)
0x0A03
0x470A /0x04
R : 0x02BA
W : 0x02BB
0x07 / 0x23
Uint
RW
Calibration point 5 for the control output (output
value)
0x0A04
0x470A /0x05
R : 0x02BC
W : 0x02BD
0x07 / 0x24
Uint
RW
Calibration point 6 for the control output (output
value)
0x0A05
0x470A /0x06
R : 0x02BE
W : 0x02BF
0x07 / 0x25
Uint
RW
Calibration point 7 for the control output (output
value)
0x0A06
0x470A /0x07
R : 0x02C0
W : 0x02C1
0x07 / 0x26
Uint
RW
Calibration point 8 for the control output (output
value)
0x0A07
0x470A /0x08
R : 0x02C2
W : 0x02C3
0x07 / 0x27
Uint
RW
Calibration point 9 for the control output (output
value)
0x0A08
0x470A /0x09
R : 0x02C6
W : 0x02C7
0x07 / 0x28
Uint
RW
Calibration point 10 for the control output (output
value)
0x0A09
0x470A
/0x0A
R : 0x02C8
W : 0x02C9
0x07 / 0x29
Uint
RW
Calibration point 1 of the control output (flow rate
value) corresponding to value of the control output
0x0A0A
0x470B /0x01
R : 0x04CA
W : 0x04CB
0x07 / 0x2A
Float
RW
Calibration point 2 of the control output (flow rate
value) corresponding to value of the control output
0x0A0C
0x470B /0x02
R : 0x04CC
W : 0x04CD
0x07 / 0x2B
Float
RW
Calibration point 3 of the control output (flow rate
value) corresponding to value of the control output
0x0A0E
0x470B /0x03
R : 0x04CE
W : 0x04CF
0x07 / 0x2C
Float
RW
Calibration point 4 of the control output (flow rate
value) corresponding to value of the control output
0x0A10
0x470B /0x04
R : 0x04D0
W : 0x04D1
0x07 / 0x2D
Float
RW
Calibration point 5 of the control output (flow rate
value) corresponding to value of the control output
0x0A12
0x470B /0x05
R : 0x04D2
W : 0x04D3
0x07 / 0x2E
Float
RW
Calibration point 6 of the control output (flow rate
value) corresponding to value of the control output
0x0A14
0x470B /0x06
R : 0x04D4
W : 0x04D5
0x07 / 0x2F
Float
RW
Calibration point 7 of the control output (flow rate
value) corresponding to value of the control output
0x0A16
0x470B /0x07
R : 0x04D6
W : 0x04D7
0x07 / 0x30
Float
RW
Calibration point 8 of the control output (flow rate
value) corresponding to value of the control output
0x0A18
0x470B /0x08
R : 0x04D8
W : 0x04D9
0x07 / 0x31
Float
RW
Calibration point 9 of the control output (flow rate
value) corresponding to value of the control output
0x0A1A
0x470B /0x09
R : 0x04DA
W : 0x04DB
0x07 / 0x32
Float
RW
Calibration point 10 of the control output (flow rate
value) corresponding to value of the control output
0x0A1C
0x470B /0x0A
R : 0x04DC
W : 0x04DD
0x07 / 0x33
Float
RW
Segments number for the Calibration curve of the
control output
0x0A1E
0x4709 /0x00
R : 0x02B2
W : 0x02B3
0x07 / 0x1F
Uint
RW
Weigh frame zero reference
0x0A31
0x4702 /0x0B
R : 0x044A
W : 0x044B
0x0A / 0x02
Float
RW
Min permissible belt load
0x0A33
0x4702 /0x09
R : 0x0202
W : 0x0203
0x07 / 0x3B
Uint
RW
Max permissible belt load
0x0A34
0x4702 /0x0A
R : 0x0204
W : 0x0205
0x07 / 0x3C
Uint
RW
Kp
0x0A35
0x470C /0x01
R : 0x04DE
W : 0x04DF
0x07 / 0x34
Float
RW
Ti
0x0A37
0x470C /0x02
R : 0x04E0
W : 0x04E1
0x07 / 0x35
Ulong
RW
Td
0x0A39
0x470C /0x03
R : 0x04E2
W : 0x04E3
0x07 / 0x36
Ulong
RW
