Scaime eNod4-B - Page 81

81/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
Name
Modbus
address
CANopen
index/sub-
index
Profibus Cyclic
IN/OUT
Acyclic
DPV1
slot /
index
Type
Access
Weight quantity per pulse on logical output
0x0057
0x4700 /0x02
R : 0x02AE
W : 0x02AF
0x07 / 0x1D
Uint
RW
Average flow rate/speed determination depth
0x0059
0x4703 /0x09
R : 0x0278
W : 0279
0x07 / 0x02
Uint
RW
Minimum weight to totalize x100
0x005B
0x4700 /0x06
R : 0x027A
W : 0x027B
0x07 / 0x03
Uint
RW
Conveyor starting alarm duration
0x005C
0x4702 /0x04
R : 0x027C
W : 0x027D
0x07 / 0x04
Uint
RW
Conveyor routing material time
0x005D
0x4702 /0x05
R : 0x027E
W : 0x027F
0x07 / 0x05
Uint
RW
Conveyor speed stabilization time
0x005E
0x4702 /0x06
R : 0x0282
W : 0x0283
0x07 / 0x07
Uint
RW
Cycle and alarm options
0x005F
0x4700 /0x01
R : 0x0280
W : 0x0281
0x07 / 0x06
Uint
RW
Nominal flow rate
0x0060
0x4701 /0x02
R : 0x04AC
W : 0x04AD
0x07 / 0x1C
Float
RW
Min permissible flow rate
0x0062
0x4701 /0x04
R : 0x0298
W : 0x0299
0x07 / 0x12
Uint
RW
Max permissible flow rate
0x0063
0x4701 /0x05
R : 0x029A
W : 0x029B
0x07 / 0x13
Uint
RW
Instant flow rate correction factor
0x002C
0x4701 /0x03
R : 0x0476
W : 0x0477
0x07 / 0x01
Float
RW
Dynamic conveyor zero band
0x0064
0x4702 /0x08
R : 0x0200
W : 0x0201
0x07 / 0x3A
Uint
RW
User fixed belt speed x100
0x0067
0x4703 /0x01
R : 0x028E
W : 0x028F
0x07 / 0x0D
Uint
RW
Weight section length
0x0068
0x4702 /0x07
R : 0x0286
W : 0x0287
0x07 / 0x09
Uint
RW
Belt number of revolutions
0x0069
0x4702 /0x03
R : 0x0288
W : 0x0289
0x07 / 0x0A
Uint
RW
Belt total length
0x006A
0x4702 /0x01
R : 0x0484
W : 0x0485
0x07 / 0x08
Float
RW
Max permissible flow rate control output
0x006C
0x4701 /0x09
R : 0x029E
W : 0x029F
0x07 / 0x15
Uint
RW
Min permissible flow rate control output
0x006D
0x4701 /0x08
R : 0x029C
W : 0x029D
0x07 / 0x14
Uint
RW
Belt inclination x100
0x006E
0x4702 /0x02
R : 0x028A
W : 0x028B
0x07 / 0x0B
Uint
RW
Flow rate/belt load control inhibit time at start
0x006F
0x4701 /0x06
R : 0x02A0
W : 0x02A1
0x07 / 0x16
Uint
RW
Flow rate/belt load control inhibit time in service
0x0070
0x4701 /0x07
R : 0x02A2
W : 0x02A3
0x07 / 0x17
Uint
RW
Speed sensor maximum number of pulses per meter
0x0071
0x4703 /0x02
R : 0x02B0
W : 0x02B1
0x07 / 0x1E
Uint
RW
Speed determination time factor
0x0072
0x4703 /0x03
R : 0x02A4
W : 0x02A5
0x07 / 0x18
Uint
RW
Nominal belt speed x100
0x0073
0x4703 /0x04
R : 0x028C
W : 0x028D
0x07 / 0x0C
Uint
RW
Min permissible belt speed
0x0074
0x4703 /0x05
R : 0x0290
W : 0x0291
0x07 / 0x0E
Uint
RW
Max permissible belt speed
0x0075
0x4703 /0x06
R : 0x0292
W : 0x0293
0x07 / 0x0F
Uint
RW
Belt speed control inhibit time at start
0x0076
0x4703 /0x07
R : 0x0294
W : 0x0295
0x07 / 0x10
Uint
RW
Belt speed control inhibit time in service
0x0077
0x4703 /0x08
R : 0x0296
W : 0x0297
0x07 / 0x11
Uint
RW
Weight to totalize (in weight unit
x1000)
0x0078
0x4700 /0x03
R : 0x04A6
W : 0x04A7
0x07 / 0x19
Ulong
RW
