The error value on analog output is defined depending on voltage or current settings as described in following table:
Setting
Analog output error mode value
0 - 5V
5.5 V
0 - 10V
11 V
4 - 20mA
no output current
0 - 20mA*
no output current
0 - 24mA*
no output current
4 mA - 20 mA with alarm at 3.6 mA
3.6 mA, voltage output is deactivated (High-Z state)
* no error detection possible in this setting
