43/95
User manual SCAIME: NU-soft-eNod4B-E-0716_236704-C.doc
Name
Input data
size in byte
Data provided
Output data
size in byte
Data consumed
Module ID
(4 bytes)
Other totals
(8 b IN)
8
Great total in weight unit
x1000 (4 bytes)
0
NA
9
General total in weight unit
x1000 (4 bytes)
Ana. Output
(2 b IN/OUT)
2
External value to control
analog output (2 bytes)
2
External value to
control analog
output (2 bytes)
10
The module “Cmd/Resp Reg” uses the mechanism of eNod4 functional commands defined in another chapter. The
only difference is for “reset” and “Restore default settings” commands which cannot be sent via cyclic exchanges
immediately after a restart of eNod4. To be able to use these commands, it must first be processed another command
(“cancel Tare” for example).
Note: The “Command register” data must be set to 0x0000 before each new command.
The “Ana. Output(2 b IN/OUT)” module allows writing directly the analog output value. This is only possible when the
analog output function assignment is set to « Level on request ».
