2 Introduction
2.2 LCD screen
AT-10 plus
Page 14
Art.-no.: 2.540043 Rev.: a
• Exercise Keys
– Exercise key - exercise ECG settings and function
– Protocol key - display/select/ edit exercise protocols
– Symptoms key - manual input of symptoms
– Begin key - start exercise test (beginning of warm-up phase) according to pro-
tocol set
– End key - stop exercise test (start of recovery phase)
– Print Report key - print final report (end of recovery phase)
– Print Rhythm key - print rhythm strip
– Next Stage key - switch to next stage
– Interrupt Stage key - interrupts the test i.e. releases load on bike/stops tread-
mill - this function can be used, for example, to administer medication - when
this key is again pressed, the test resumes from the same position
– Load key - overwrite protocol and define load
(3) Memory, Storage and transmission Keys:
– Memory key - gives access to the stored recordings - memory and transmission
settings are also defined here
– Store Data key - initiates data storage to internal memory of the current record-
ing - the location where the recording is stored in defined in the memory set-
tings.
– Send Data key - initiates transmission over the defined interface of the current
recording - the location where the recording is sent is defined in memory set-
tings
– Get Data key - initiates data reception from another location - the location from
where the data is received is defined in the memory settings
(4) Patient Data key - Input of patient data
(5) Direct function keys including:
– Print Screen key - print the displayed screen
– Copy 1 and Copy 2 keys - print a copy of current recording in format 1 or format
2
– Man Start key - imitate real time printout
– Auto Start key - take auto recording
– Stop key - stop real time printout / advance paper to beginning of new page
(6) Replace Paper key - extend or retract the paper tray for paper replacement
(7) On/Off key - switch the unit on or off
(8) Menu navigation keys including:
– Menu key - give access to system settings
– Confirm key - confirm current / displayed setting
– Left arrow key - move cursor to the left / select next menu option
– Right arrow key - move cursor to the right / select previous menu option
– Up arrow key - move cursor or menu bar up
– Down arrow key - move cursor or menu bar down
– (see page 19)
(9) Further Function Keys for:
– NIPB key - take or enter non-invasive blood pressure measurements
– SPIRO key - spirometry program (requires spiro sensor connected to the spiro
RS-232 interface)
