Schiller AT-10 plus - Communication Module

Page 47
Replacing Major Components 6
AT-10 plus Service Handbook Opening the case 6.4
Art.-no.: 2.540043 Rev.: a
6.4.3 Communication module
1. The complete electronic assembly must be removed to remove the communica-
tion module.
2. Remove the recessed screws securing the assembly to the casing.
3. Gently lift the assembly away from the casing and remove connectors.
