9 Technical Data
9.1 System
AT-10 plus
Page 60
Art.-no.: 2.540043 Rev.: a
9 Technical Data
9.1 System
Dimensions
348 x 288 x 87 mm, approx. 4.2 kg.
Monitor • Backlit for graphic and LCD alphanumeric representation
• Resolution: 800 x 600 dots
Power supply
Mains Voltage
Power consumption
Battery
• 220 - 240 V (nominal), 50 / 60 Hz; 100 - 115 V (nominal), 50 / 60 Hz;
• 14VA to 28VA (Max)
• Operation with built-in rechargeable battery
Battery
Capacity
Battery Life
Recharging time
Nickle Cadnium 9.6 V
• 2 hours normal use, 3 hours Standby
• Under normal operating conditions, 4 years
• 90 %: approx. 7 hours, 100 %: approx. 15 hours
Printer
Frequency range
Chart paper
Chart print-out speed
Sensitivity
Recording tracks
High-resolution thermal printing, 8 dots/mm (amplitude axis), 40 dots/mm (time ax-
is), @ 25 mm/s
• 0.05 ... 150 Hz (IEC/AHA)
• Thermo reactive, Z-fold, 14 x 21 cm (DIN A4; letter size)
• 5/12.5/25/50 mm/s (manual print)
• 5/10/20 mm/ms (manual print)
• 3 to 12 channels, positioned optimally on 200 mm, automatic baseline adjustment
Interfaces • RS-232 connector for Treadmill
• RS-232 connector for Ergometer
• RS232 connector for pneuotach sensor
• VGA connector for external monitor
• ECG cable Interface
• DC input - 0.5V/cm
• DC output - 0.5V/cm
• Further interface options with the Communications Module
Memory
Storage for up to 40 ECG recordings. Further memory available with the extended
memory option.
Environmental conditions
Operating temperature,
Storage temperature,
Relative humidity
Pressure during operation
• 10 ... 40 °C
• -10 ... 50 °C
• 25 ... 95 % (no condensation)
• 700 ... 1060 hPa
