Final Report ST Trends A graph of the ST amplitude and slope. Select Yes to print, or No to suppress
printing.
ST-HR Diagram (not
available at time of print)
A graph of the ST amplitude against heart rate. Select Yes to print, or No to
suppress printing.
Interpretation (not available
at time of print)
Yes (print) or No (suppress printing).
Average Cycle (not
available at time of print)
Print Average cycles. Select Compact, All or No.
Speed (not available at time
of print)
Printing speed (for average cycles when 'Compact' or 'All' selected above). Set
to 25mm/s or 50 mm/s.
Print Rhythm (R1) Print rhythm lead R1 Yes or No.
Rhythm settings Rhythm record lead (R1) Select the lead for rhythm recording (for rhythm strip when Rhythm (R1)
selected in Final Report above) - select either I, II, III, aVR, aVL, aVF, V1 - V6.
Speed Select Rhythm strip printing speed. Set to 6.25 mm/s or 12.5 mm/s.
Sensitivity Select Rhythm strip sensitivity (amplitude). Set to 5 mm/mV or 2.5 mm/mV.
QRS Settings
ST Amplitude
Measurement
During the exercise test, the ST amplitude is measured continuously. The
position of the amplitude measurement point can be set to 20, 40, 60 or 80 ms
after the j-point.
Lead for Enlarged QRS Select lead for zoom view. The enlarged QRS complex appears to the right of
the screen when the exercise test is started. This enlarged lead is averaged
over 10 beats. This lead is also used for ST measurements.
Unit of ST Measurement Select between mm or mV.
Interpretation Enter / Edit exercise interpretation.
Validated by and date Enter who validated the recording and the date of validation.
