8.4 Electromagnetic interferences
The FRED easy® is intended to be used in the electromagnetic environments listed
in the following tables. The owner or user of the FRED easy® has to ensure that the
device is operated in an adequate environment.
8.4.1 Electromagnetic emissions
8.4.2 Electromagnetic immunity
Emission measurement
Compliance with the regula-
tions
Electromagnetic environment - explanations
HF emissions
CISPR 11
Group 1 FRED easy® only uses HF energy for internal functions. Therefore,
HF emissions are very low and interferences with electronic devices
nearby are unlikely.
HF emissions
CISPR 11
Class B
FRED easy® is suitable for use in all establishments, including do-
mestic establishments and those directly connected to the public
low-voltage power supply network that supplies buildings used for
domestic purposes.
Harmonics IEC 61000-3-2 Not applicable
Voltage fluctuations
IEC 61000-3-3
Not applicable
Interference testing IEC 60601 test level Conformity level Electromagnetic environment - explanations
Electrostatic dis-
charge
IEC 61000-4-2
± 6 kV contact
± 8 kV air
IEC 60601-1
conformity
Floors should be made of wood, concrete or ceramic tiles. If floors
are covered with synthetic material, relative humidity should be at
least 30%.
Electrical fast tran-
sient/burst
IEC 61000-4-4
± 2 kV for power supply lines
± 1 kV for input/output lines
Not applicable
Surge
IEC 61000-4-5
± 1 kV between conductors
± 2 kV conductor-earth
Not applicable
Voltage dips, short in-
terruptions and volt-
age variations on
power supply input
lines
IEC 61000-4-11
< 5 % U
T
(> 95 % dip in U
T
) for
0.5 cycle
40 % U
T
(60 % dip in U
T
) for 5 cy-
cles
70 % U
T
(30 % dip in U
T
) for 25 cy-
cles
< 5 % U
T
(> 95 % dip in U
T
) for 5 s
Not applicable
Power frequency (50/
60 Hz) magnetic field
IEC 61000-4-8
3 A/m IEC 60601-1
conformity
Power frequency magnetic fields should be that of a typical com-
mercial and/or hospital environment.
Note: U
T
indicates the AC voltage of the mains before the test level.
