Assembly
52
12.00 | SWS | Assembly and Operating Manual | en | 389456
Ø Insert dowel pins(6) on the cover plate/SWK into the bores on
the adapter plate.
Ø Apply screw lock to screws(8).
Ø Secure SWK(7) to adapter plate(3) with screws(8).
✓ Observe the tightening torque for the mounting screws.
Item Mounting SWK071
5 Alignment pin Ø6 x 20
8 Mounting screw according to
standard
M6x40,
DIN EN ISO 4762
Strength class 8.8
Max. tightening torque [Nm] 10.17
Threadlocker Loctite ® 242
