IRD-2600 / IRD-2800
Integrated Receiver Decoders
P/N 2349-72784-00 Page 3-61
Table 3-21: Graphics Display (GFX-DSPL) Sub Menu Commands
OPTION DESCRIPTION
Graphic Test
Graphics Overlay Testing
Enables the user to test the capabilities of the graphics function.
Available options:
NONE: Test disabled
COLOR LOOK-UP TABLE: 16 squares color test pattern displayed on
the screen, to test the 16-color look-up table.
Product Status
Product Status Overlays
Selects for display graphic overlays with various Product Status reports.
Options available:
MAIN OPERATION: see example in Figure 3-28.
FRONT END OPERATION: see example in Figure 3-29.
PRODUCT CONFIGURATION: see example in Figure 3-30.
PRODUCT REVISION: see example in Figure 3-31.
PRODUCT SETUPS: see example in Figure 3-32.
NONE: No Product Status overlay.
NOTE: (*)
Same pages (marked by *above) require more than one page to display
all information. Pressing the ENTER Touch Pad on the Front Panel
displays the next page.
Stream PSI-SI
Stream PSI-SI Overlays
Selects for display graphic overlays with data from the received stream
PSI/SI tables.
Options available:
PROGRAM ASSOCIATION TABLE (PAT): see example in Figure 3-33.
PROGRAM MAP TABLE (PMT): see example in Figure 3-34.
SERVICE DESCRIPTION TABLE (SDT): see example in Figure 3-35.
NETWORK INFORMATION TABLE (NIT): see example in Figure 3-36.
NONE: No PSI/SI based overlay.
Logo Text Insertion
Logo Text Overlay.
Inserts the Logo text graphic overlay.
Options available:
DISABALE (Default): Disables display of logo.
LEFT BOTTOM: displays the logo on the bottoms - Left corner of the
screen.
LEFT TOP: Displays the logo on the top – left corner of the screen.
RIGHT BOTTOM: Displays the logo on the bottom – right corner of the
screen.
RIGHT TOP: Displays the logo on the top – right corner of the screen.
