User Manual
Chapter 3. Operation
Page 3-62 P/N 2349-72784-00
Figure 3-28: Product Status / Main Operation Overlay - Example
Figure 3-29: Product Status / Front End Operation Overlay - Example
HARDWARE status : ALL OK.
OPERATION status : DECODING.
BIT STREAM status : ALL OK.
PROGRAM PIDs (hex) : Video =00A5, Audio1=0064, Audio2=001F, Pcr=00A5
: Teletext=002F, Data1 =0021, Data2 =0021.
SERVICE status : Active in PSI (0006-MTV 1-EN1- TV).
GPI status : CLOSE.
VIDEO operation mode : PLAY.
VIDEO format : PAL BG.
VIDEO chroma format : 4:2:0
VIDEO bit rate (dec): 06960000 Bit/Sec.
VIDEO resolution (dec): 480 * 576.
VIDEO aspect ratio : SOURCE= 4:3
: DISPLAY= TRANSPARENT - PAN SCAN ON.
VIDEO teletext info : EVEN= 05, ODD= 05. EBU Subtitling page= 541.
AUDIO digital output : MPEG DECODED (IEC958).
AUDIO1 analog output : PLAY - STEREO.
AUDIO1 bit rate (dec) : 192000 Bit/Sec.
AUDIO1 sampling (dec) : 48.0 kHz.
AUDIO2 analog output : PLAY.
AUDIO2 bit rate (dec) : 000000 Bit/Sec.
AUDIO2 sampling (dec) : 00.0 kHz.
LNB local oscillator (dec) : UNIVERSAL (Ku).
LNB power (polarization) : 14 Volts (Vertical).
LNB 22 Khz : OFF.
FREQUENCY (dec) : 11238000 Khz.
SYMBOL rate (dec) : 27500.00 KBaud.
VITERBI rate - FEC (dec) : 3/4.
SPECTRAL inversion : NORMAL.
Eb/N0 (dec) : 10.09 dB.
Link Margin (dec) : +05.0 dB.
SIGNAL quality (dec) : 057 %.
TUNER AGC (dec) : 042 %.
VITERBI BER (dec) : 0.0e-7
FREQUENCY offset (dec) : +00000 Khz.
