Step 10: Remove piping stopper
Remove nuts on the centrifugal blade and then
pull the centrifugal blade outwards to remove it.
.
Step 11: Remove water tray assembly
Remove the two (2) screws that fixes the water
tray in place. Pull the water tray outwards to
remove it.
Step 12: Remove electric box assembly
Remove the one screw that fixes the electric
box assembly in place. Disconnect all
connections and then pull the electric box
assembly outwards to remove it.
Step 13: Remove electric box assembly
Remove the one screw that fixes the electric
box assembly in place. Disconnect all
connections and then pull the electric box
assembly outwards to remove it.
