13. Specifications
13.1 Indoor Units
13.1.1 Wall Mounted A
Model Number
SHE9H4ZIGX
SHE12H4ZIGX
SHE18H4ZIGX
Product Code
243-2003-E
243-2004-E
243-2005-E
Performance
& Electrical
Rated Voltage
208-230V AC / 1 PH
208-230V AC / 1 PH
208-230V AC / 1 PH
Control
Remote (standard) or
Wall (optional)
Remote (standard) or
Wall (optional)
Remote (standard) or
Wall (optional)
Setting Range
61°F to 86°F
61°F to 86°F
61°F to 86°F
Cooling Capacity (BTU/H)
(Min. ~ Max.)
9000 (3100~9600)
12000 (3100~13000)
18000 (6210~22000)
Heating Capacity (BTU/H)
(Min. ~ Max.)
9800 (2200~11000)
13000 (2400~14000)
19800 (4100~22000)
Wire Size / No. of Conductors
4C- 14 AWG (Recommended)
4C- 14 AWG (Recommended)
4C- 14 AWG (Recommended)
Indoor Air Circulation (CFM)
(Turbo / H / M / L)
306/ 253 /218 /171
330/ 288/ 258 /206
488/ 441/ 383/ 324
Dehumidifying Volume (pts/h)
2.54
2.96
4.22
FAN Motor
Fan Motor Speed (RPM)-Cooling
Fan Motor Speed (RPM)-Heating
(Turbo / H / M / L)
1400/1150/1050/900
1450/1250/1150/1050
1500/1150/1050/900
1450/1250/1150/1050
1500/1150/1050/950
1500/1200/1100/1000
Output of Fan Motor (W)
10
10
20
Fan Motor Capacitor (ufd)
1
1
1.5
Fan Motor RLA ( A)
0.17
0.17
0.32
Fan Type
Cross Flow Fan
Cross Flow Fan
Cross Flow Fan
Diameter-Length (in)
3.35 – 26.34
3.35 – 26.34
3.86 – 28.86
Evaporator
Evaporator
Aluminum fin - copper tube
Aluminum fin - copper tube
Aluminum fin - copper tube
Pipe Diameter (in)
0.276
0.276
0.276
Row-Fin Gap (in)
2-0.06
2-0.06
2-0.06
Coil length(L) x height(H) x
coil width(L) (in)
25.9 x 11.2 x 1
25.9 x 11.2 x 1
29 x 12 x 1
Design Data
Swing Motor Model / Output (W)
(for horizontal louver)
MP28VB / 2
MP28VB / 2
MP28VB / 2.5
Fuse(A)
3.15
3.15
3.15
High Pressure (PSI)
550
550
500
Low Pressure (PSI)
240
240
240
Auto Restart
Yes
Yes
Yes
Sound Pressure Level dB(A)
(Turbo / H / M / L)
46 / 38 / 30 / 28
48 / 38 / 30 / 28
46 / 43 / 40 / 35
Sound Power Level dB(A)
(Turbo / H / M / L)
56 / 48 / 40 / 38
58 / 48 / 40 / 38
56 / 53 / 50 / 45
Flare Liquid line
1/4 "
1/4 "
1/4 "
Flare Suction line
3/8"
1/2"
1/2"
Dimensions &
Weight
Dimensions of Unit
(W / D / H) (approx in)
34.3 / 7 / 11
34.3 / 7 / 11
37.8 / 7.7 / 11.8
Dimension of Package
(W / D / H) (approx in)
36.9 / 14.9 / 10.8
36.9 / 14.9 / 10.8
40.9 / 15.5 / 11.6
Net / Gross Weight (lb)
24.3 / 33.1
24.3 / 33.1
28.7 / 39.7
