Seabreeze SHE9H4ZIGX - Floor;Ceiling; Ducted

4
3.1.4 Floor/Ceiling
Model
A
B
H
C
D
SMZFC9H4ZIGX
48.03”
8.86”
27.56”
45.59”
11.02”
SMZFC12H4ZIGX
SMZFC18H4ZIGX
SMZFC24H4ZIGX
A B
C
D
H
3.1.4 Ducted
Model
A
B
C
D
E
F
G
H
I
J
SMZD9H4ZIGX
29.21"
19.33”
26.06”
24.41”
27.56”
24.21”
30.79”
6.14”
7.87”
25”
SMZD12H4ZIGX
SMZD18H4ZIGX
37.09”
19.33”
33.94”
32.28
35.43”
24.21”
38.66”
6.14”
7.87”
25”
SMZD21H4ZIGX
44.96”
19.33”
41.81
40.16”
43.31”
24.21”
46.54”
6.14”
7.87”
25”
SMZD24H4ZIGX
A
B
D
E
G
I
C
J
F
H
Electric Box Liquid Pipe Gas Pipe
Drain Pipe
Downward Return Air
Backward
Return Air
