Seabreeze SHE9H4ZIGX - Five Port

119
13.1.2 Wall Mounted B
Model Number
SHE9H4ZIGB
SHE12H4ZIGB
SHE18H4ZIGB
SHE24H4ZIGB
Product Code
243-2007-E
243-2008-E
243-2009-E
243-2010-E
Performance
& Electrical
Rated Voltage
208-230V AC / 1 PH
208-230V AC / 1 PH
208-230V AC / 1 PH
208-230V AC / 1 PH
Min. / Max. Operating Voltage
187 / 253 VAC
187 / 253 VAC
187 / 253 VAC
187 / 253 VAC
Cooling Capacity (BTU/H)
(Min. ~ Max.)
9000 (3500~9600)
12000 (3100~13000)
18000 (5970~22350)
21400 (9600~25000)
Heating Capacity (BTU/H)
(Min. ~ Max.)
9800 (2200~11000)
13000 (2400~14000)
19800 (4100~22000)
23000 (4300~26000)
Indoor Air Circulation (CFM)
(Turbo / H / M / L)
306/ 277 /253 /218
335/ 277/ 253 /218
500/ 459/ 383/ 324
589/ 471/ 412/ 353
Dehumidifying Volume (pts/h)
1.69
2.96
3.8
5.28
FAN Motor
Model
FN20X-PG
FN20X-PG
FN20W-PG
FN60B-ZL
Fan Motor Speed (RPM)-Cooling
Fan Motor Speed (RPM)-Heating
(Turbo / H / M / L)
1260/1100/950/750
1320/1200/1100/950
1330/1100/950/750
1350/1170/1050/950
1500/1200/1050/900
1500/1250/1150/1050
1500/1200/1050/900
1450/1150/1020/950
Output of Fan Motor (W)
20
20
20
60
Fan Motor Capacitor (ufd)
1
1
1.5
N / A
Fan Motor RLA ( A)
0.2
0.2
0.32
0.24
Fan Type
Cross Flow Fan
Cross Flow Fan
Cross Flow Fan
Cross Flow Fan
Diameter-Length (in)
3 5/8 – 25 2/5
3 5/8 – 25 2/5
3 6/7 – 28
3 6/7 – 30 1/8
Evaporator
Evaporator
Aluminum fin -
copper tube
Aluminum fin -
copper tube
Aluminum fin -
copper tube
Aluminum fin -
copper tube
Pipe Diameter (in)
0.276
0.276
0.276
0.276
Row-Fin Gap (in)
2-0.06
2-0.06
2-0.06
2-0.06
Coil length(L) x height(H) x coil
width(L) (in)
27.2 x 10.5 x 1
27.2 x 10.5 x 1
28.1 x 12 x 1
30 1/8 x 13 1/2 x 1
Design Data
Swing Motor Model / Output (W)
(for horizontal louver)
MP24AA / 2
MP24AA / 2
MP28VB / 2.5
MP35XX / 3
Fuse(A)
3.15
3.15
3.15
3.15
High Pressure (PSI)
550
550
550
550
Low Pressure (PSI)
240
240
240
240
Auto Restart
Yes
Yes
Yes
Yes
*Remote
Yes
Yes
Yes
Yes
Wall Control (optional)
Yes
Yes
Yes
Yes
Sound Pressure Level dB(A)
(Turbo / H / M / L)
42 / 38 / 35 / 32
44 / 39 / 36 / 33
49 / 44 / 40 / 35
53 / 45 / 41 / 37
Sound Power Level dB(A)
(Turbo / H / M / L)
52 / 48 / 45 / 42
54 / 49 / 46 / 43
59 / 54 / 50 / 45
63 / 55 / 51 / 47
Flare Liquid line
1/4"
1/4"
1/4"
1/4"
Flare Suction line
3/8"
3/8"
1/2"
5/8"
Dimensions
& Weight
Dimensions of Unit (W / D / H)
(approx in)
33.3 / 7.1 / 10.8
33.3 / 7.1 / 10.8
37 / 7.9 / 11.7
39.6 / 8.6 / 12.4
Dimension of Package (W / D / H)
(approx in)
36.1 / 10.2 / 14.6
36.1 / 10.2 / 14.6
39.9 / 15.6 / 11.3
42.4 / 15.7 / 12.9
Net / Gross Weight (lb)
22 / 27.6
22 / 27.6
28.7 / 35.3
29.8 / 37.5
