7.2.2 Quad Port Options
SMZ24H46ZOGX
NOTE: Do not mismatch or connect to an outdoor unit other than the designed matched system.
This system must be used with a minimum of two (2) indoor units (evaporators).
Two (2) Indoor Units
Three (3) Indoor Units
9K + 9K
9K + 12K
9K + 9K + 9K
9K + 18K
9K + 9K + 12K
12K + 12K
12K + 18K
The configuration shown below will work but it is not recommended if all indoor units may require simultaneous continuous operation at full efficiency.
9K + 12K + 12K
7.2.3 Quad Port Options
SMZ30H46ZOGX
NOTE: Do not mismatch or connect to an outdoor unit other than the designed matched system.
This system must be used with a minimum of two (2) indoor units (evaporators).
Two (2) Indoor Units
Three (3) Indoor Units
Four (4) Indoor Units
9K + 9K
9K + 9K + 9K
9K + 12K
9K + 9K + 12K
9K + 18K
9K + 9K + 18K
9K + 9K + 9K + 9K
12K + 12K
9K + 12K + 12K
12K + 18K
12K + 12K + 12K
18K + 18K
The configurations shown below will work but it is not recommended if all indoor units may require simultaneous continuous operation at full efficiency.
18K + 18K
9K + 12K + 18K
9K + 9K + 9K + 12K
12K + 12K + 18K
9K + 9K + 12K + 12K
