7. System Configuration
7.1 System Structure
For this multi-zone air conditioning system, the outdoor unit is able to drive the indoor units which can
be different types as shown below. The console indoor unit can be controlled only by the remote control.
The other indoor units can be controlled by either the remote control or the wall control. The outdoor
unit will run if any of the indoor units sends a request for heating or cooling. All indoor units will stop
once the outdoor unit is turned off.
7.2 Configuration Options
7.2.1 Dual Port Options
SMZ18H46ZOGX
NOTE: Do not mismatch or connect to an outdoor unit other than the designed matched system.
