14. Appendix
14.1 Appendix I: Resistance of Ambient Temperature Sensor (15K) for Indoor/Outdoor Units (F1,F3)
Temp. (°F)
Resistance (kΩ)
Temp. (°F)
Resistance (kΩ)
Temp. (°F)
Resistance (kΩ)
Temp. (°F)
Resistance (kΩ)
-2.2
138.1
68.0
18.75
138.2
3.848
208.4
1.071
-0.4
128.6
69.8
17.93
140.0
3.711
210.2
1.039
1.4
121.6
71.6
17.14
141.8
3.579
212.0
1.009
3.2
115.0
73.4
16.39
143.6
3.454
213.8
0.980
5.0
108.7
75.2
15.68
145.4
3.333
215.6
0.952
6.8
102.9
77.0
15.00
147.2
3.217
217.4
0.925
8.6
97.40
78.8
14.36
149.0
3.105
219.2
0.898
10.4
92.22
80.6
13.74
150.8
2.998
221.0
0.873
12.2
87.35
82.4
13.16
152.6
2.896
222.8
0.848
14.0
82.75
84.2
12.60
154.4
2.797
224.6
0.825
15.8
78.43
86.0
12.07
156.2
2.702
226.4
0.802
17.6
74.35
87.8
11.57
158.0
2.611
228.2
0.779
19.4
79.50
89.6
11.09
159.8
2.523
230.0
0.758
21.2
66.88
91.4
10.63
161.6
2.439
231.8
0.737
23.0
63.46
93.2
10.20
163.4
2.358
233.6
0.717
24.8
60.23
95.0
9.779
165.2
2.280
235.4
0.697
26.6
57.18
96.8
9.382
167.0
2.206
237.2
0.678
28.4
54.31
98.6
9.003
168.8
2.133
239.0
0.660
30.2
51.59
100.4
8.642
170.6
2.064
240.8
0.642
32.0
49.02
102.2
8.297
172.4
1.997
242.6
0.625
33.8
46.60
104.0
7.967
174.2
1.933
244.4
0.608
35.6
44.31
105.8
7.653
176.0
1.871
246.2
0.592
37.4
42.14
107.6
7.352
177.8
1.811
248.0
0.577
39.2
40.09
109.4
7.065
179.6
1.754
249.8
0.561
41.0
38.15
111.2
6.791
181.4
1.699
251.6
0.547
42.8
36.32
113.0
6.529
183.2
1.645
253.4
0.532
44.6
34.58
114.8
6.278
185.0
1.594
255.2
0.519
46.4
32.94
116.6
6.038
186.8
1.544
257.0
0.505
48.2
31.38
118.4
5.809
188.6
1.497
258.8
0.492
50.0
29.90
120.2
5.589
190.4
1.451
260.6
0.480
51.8
28.51
122.0
5.379
192.2
1.408
262.4
0.467
53.6
27.18
123.8
5.197
194.0
1.363
264.2
0.456
55.4
25.92
125.6
4.986
195.8
1.322
266.0
0.444
57.2
24.73
127.4
4.802
197.6
1.282
267.8
0.433
59.0
23.60
129.2
4.625
199.4
1.244
269.6
0.422
60.8
22.53
131.0
4.456
201.2
1.207
271.4
0.412
62.6
21.51
132.8
4.294
203.0
1.171
273.2
0.401
64.4
20.54
134.6
4.139
204.8
1.136
275.0
0.391
66.2
19.63
136.4
3.990
206.6
1.103
276.8
0.382
