Step 1: Remove front panel
Pull down on the clip on the front grill until the grill is
open (as shown in the diagram; arrow represents the
position of the buttons; there are two clips for each
“grill”).
Step 2: Remove left and right plates
Remove the screws (as shown in diagram) with a
screwdriver and then push upward to remove the
right and left finishing plates. (The arrows in the
diagram show the position of the screws.)
Step 3: Remove panel parts
Remove the screws shown by the arrow in the graph
(two (2) on both right and left and four (4) in the front)
with the screwdriver and then remove the panel parts.
