Seabreeze SHE9H4ZIGX - Appendix IV: Pressure on Service Port.

123
13.1.6 Ducted
Model Of Indoor Unit
SMZD9H4ZIGX
SMZD12H4ZIGX
SMZD18H4ZIGX
SMZD21H4ZIGX
SMZD24H4ZIGX
Product Code
243-6011-E
243-6012-E
243-6013-E
243-6014-E
243-6015-E
Performance
& Electrical
Rated Voltage
208-230V AC / 1 PH
208-230V AC / 1 PH
208-230V AC / 1 PH
208-230V AC / 1 PH
208-230V AC / 1 PH
Control
Wall (standard) or
Remote(optional)
Wall (standard) or
Remote(optional)
Wall (standard) or
Remote(optional)
Wall (standard) or
Remote(optional)
Wall (standard) or
Remote(optional)
Setting Range
61°F to 86°F
61°F to 86°F
61°F to 86°F
61°F to 86°F
61°F to 86°F
Cooling Capacity (BTU/H)
8500
11900
15300
20400
23800
Heating Capacity (BTU/H)
9500
13100
18700
22600
27400
Wire Size / No. of Conductors
4C- 14 AWG
(Recommended)
4C- 14 AWG
(Recommended)
4C- 14 AWG
(Recommended)
4C- 14 AWG
(Recommended)
4C- 14 AWG
(Recommended)
Indoor Air Circulation (CFM)
(High Fan Speed)
265
294
412
589
589
Dehumidifying Volume(pts/h)
1.69
2.96
3.8
4.23
5.28
FAN Motor
Fan Model
FG30A
FG40A
FG60A
FG20E
FG20E
Fan Motor Speed (SH / H / M / L)
1230 / 970 / 760 / 640
1130 / 960 / 830 / 700
1000 / 920 / 780 / 720
1160 / 985 / 800 / 680
1160 / 985 / 800 / 680
Output of Fan Motor (W)
40
49
75
22.5
22.5
Fan Motor Capacitor (ufd)
1.5
3
3
3
3
Fan Motor RLA ( A)
0.35
0.35
0.43
0.54
0.54
Fan Type
Centrifugal
Centrifugal
Centrifugal
Centrifugal
Centrifugal
Fan Quantity
2
2
3
4
4
Diameter-Length (in)
5.49 – 5.30
5.49 – 5.30
5.49 – 5.30
5.49 – 5.30
5.49 – 5.30
Evaporator
Evaporator
Aluminum fin – Inner
grooved copper tube
Aluminum fin – Inner
grooved copper tube
Aluminum fin – Inner
grooved copper tube
Aluminum fin – Inner
grooved copper tube
Aluminum fin – Inner
grooved copper tube
Pipe Diameter (in)
0.28
0.28
0.28
0.28
0.28
Row-Fin Gap (in)
2-0.06
3-0.06
3-0.06
3-0.06
3-0.06
Coil length(L) x height(H) x
coil width(W) (in)
20.7 x 8.3 x 1.0
20.7 x 8.3 x 1.0
28.5 x 8.3 x 1.5
36.4 x 8.3 x 1.5
36.4 x 8.3 x 1.5
Design Data
Fuse(A)
3.15
3.15
3.15
3.15
3.15
High Pressure (PSI)
550
550
550
550
550
Low Pressure (PSI)
240
240
240
240
240
Auto Restart
Yes
Yes
Yes
Yes
Yes
Condensate Pump
Yes
Yes
Yes
Yes
Yes
Condensate Pump lift (ft)
3.6
3.6
3.6
3.6
3.6
Sound Pressure Level dB(A)
(H / L)
37 / 31
39 / 32
41 / 33
42 / 34
42 / 34
Sound Power Level dB(A)
(H / L)
47 / 41
49 / 42
51 / 43
52 / 44
52 / 44
Flare Liquid line
1/4"
1/4"
1/4"
3/8"
3/8 "
Flare Suction line
3/8"
3/8"
1/2"
5/8"
5/8"
Dimensions &
Weight
Dimensions of Unit
(W / D / H) (approx in)
27.6 / 24.2 / 7.9
27.6 / 24.2 / 7.9
35.4 / 24.2 / 7.9
43.3 / 24.2 / 7.9
43.3 / 24.2 / 7.9
Dimension of Package
(W / D / H) (approx in)
35.2 / 29.3 / 12.0
35.2 / 29.3 / 12.0
44.2 / 29.3 / 12.0
52.1 / 29.3 / 12.0
52.1 / 29.3 / 12.0
Net / Gross Weight (lb)
48.51 / 59.54
50.72 / 63.95
59.54 / 79.38
68.36 / 90.41
68.36 / 90.41
