13.2 Outdoor Units
13.2.1 Dual Port
Model Number
SMZ18H46ZOGX
Product Code
243-1004-C
Rated Voltage & Frequency and Phase
208-230 / 1PH
Min./ Max. Operating Voltage
187 / 253 VAC
Circuit Breaker Size (A)
20
Working Temperature Range (°F)
Cooling: 14 to 118; Heating: 5 to 81
Refrigerant (R410A), (oz.)
47.62
Min. Circuit Ampacity (A)
15
Low Ambient Cooling Function
Yes
Sound Power Level dB(A) (Max.)
66
Cooling
Rated Capacity (Btu/h)
18,000
Capacity Invert Range (Btu/h)
7,000 - 21,000
Rated Power Input (W)
1,650
Power Input Range (W)
680 - 2,800
Total Input Current (Cooling)
10.48 / 10.22 A
SEER
16
Heating
Rated Capacity (Btu/h)
19,000
Capacity Invert Range (Btu/h)
8,530 - 22,600
Rated Power Input (W)
1,640
Power Input Range (W)
680 - 2,800
Total Input Current (Heating)
10.48 / 10.22 A
HSPF
8.2
Fan Motor
Fan Type
Axial Fan
Output (W)
60
Capacitor (UFD)
3.5
Fan Motor RLA (A)
0.54
Fan Speed (RPM)
830 / 670 / 500
Outdoor Fan
Fan Blade Diameter (in)
17.52
Air Flow Volume of Outdoor Unit (CFM)
1530 / 1354 / 942
Compressor
Model
SNB130FGYMC
TYPE
Rotary
Brand
MITSUBISHI
RLA
9.56
Input (W)
1245
Crankcase Heater Input (W)
25 ± 7
Oil Type
PVE / FV50S
Overload Protector
1NT11L-6578
Condenser
Number of Rows
2
Fin spacing (in)
0.055
Fin Type
Aluminum, Louvered
Tube Outside Dia.(in)
0.313
Coil Length x Height x Width (in)
27.56 x 21.65 x 1.5
Number of circuits
2
Defrosting Method
Automatic Defrosting
Dimensions &
Weight
Unit Dimensions (W x H x D) (in)
35.39 x 23.46 x 14.88
Packing Dimensions (W x H x D) (in)
37.32 x 25.39 x 16.54
Net / Gross Weight (lb)
94.8 / 105.82
Connection
Flare Liquid line
1/4 "
Flare Suction line [*1]
3/8" [*1]
Service Port Fitting
1/2" - 20 UNF
High Pressure (psi)
550
Low Pressure (psi)
240
Design Length (ft)
24.6 (for each indoor unit) (49.2’ total)
Max Line Set Vertical Height (ft)
16.4
Max Line Set Length (ft)
32.8 (for each indoor unit)
Max Line Set Length (ft)
65.6 (total)
Charge over Design Length [*2] (oz. / ft)
0.22 (over 49.2’)
Wiring (Indoor to Outdoor)
4C- 14 (Recommended)
Wiring (Outdoor unit to Power Disconnect)
3C- 12 AWG (minimum)
*1. 12,000 BTU indoor units use a 1/2" to 3/8" adaptor joint that is included with the unit.
*2. When the total length of liquid line is over 49.2 ft, the additional refrigerant charge is required.
