8. Installation
8.1 Placing the Indoor Unit
GENERAL WARNINGS!
Ensure the proper clearance and mounting requirements are met as shown.
Ensure airflow from the inlet and outlet area of the indoor unit is not obstructed.
Make sure that there is enough space for care and maintenance.
Do not install unit in a humid area (i.e. laundry room, bathroom).
Ensure the installation area is level.
Select a place where the condensate water can be easily drained.
Ensure unit is installed away from heat sources, leakages of inflammable, explosive substances, or
smog.
The power cords and connection lines of the indoor and outdoor units must be at least 3.3 ft. away
from the TV set or radio to avoid the image interference and noise.
Select an area that is strong enough to withstand 4 times the weight of the indoor unit. This prevents
vibration and noise. If not, reinforce before installation. (Refer to the installation cardboard template
for more details.)
8.1.1 Wall Mounted
