11. Troubleshooting
NOTE: All pictures used in this section are for reference only. Actual products may be different.
WARNING!
Electricity is still kept in the capacitors even when the power supply is shut off or disconnected. Do not
forget to discharge the electricity in the capacitors before troubleshooting.
Electrolytic Capacitors
(CAUTION! HIGH VOLTAGE!)
For other models, please connect the discharge resistance (approximately 100Ω 40W) or soldering iron
(plug) between the “+” and “-“ terminals of the electrolytic capacitor on the opposite side of the
outdoor PCB.
NOTE: The picture above is for reference only. The actual plugs and capacitors may be different.
