Seabreeze SHE9H4ZIGX - Five Port (SMZ42 H46 ZOGX)

86
12.1.3 Five Port (SMZ42H46ZOGX)
12.1.3.1 Disassembly and Reassembly of Fan Blades
Step 1: Remove top cover
Remove the screws on the cover plate by
using a screwdriver. Then remove cover
plate.
Step 2: Remove front panel
Remove the screws on the front panel by
using a screwdriver. Then remove the front
panel.
