7.2.4 Five Port Options
SMZ42H46ZOGX
NOTE: Do not mismatch or connect to an outdoor unit other than the designed matched system.
This system must be used with a minimum of two (2) indoor units (evaporators).
Two (2) Indoor Units
Three (3) Indoor Units
Four (4) Indoor Units
Five (5) Indoor Units
9K + 9K
9K + 12K
9K + 18K
12K + 12K
12K + 18K
18K + 18K
12K + 21K
12K + 24K
18K + 21K
18K + 24K
21K + 21K
21K + 24K
9K + 9K + 9K
9K + 9K + 12K
9K + 9K + 18K
9K + 12K + 12K
9K + 12K + 18K
9K + 18K + 18K
12K + 12K + 12K
12K + 12K + 18K
12K + 18K + 18K
9K + 9K + 21K
9K + 9K + 24K
9K + 18K + 21K
9K + 12K + 21K
9K + 12K + 24K
12K + 12K + 21K
9K + 9K + 9K + 9K
9K + 9K + 9K + 12K
9K + 9K + 9K + 18K
9K + 9K + 12K + 12K
9K + 9K + 12K + 18K
9K + 12K + 12K + 12K
9K + 9K + 9K + 9K + 9K
The configurations shown below will work but it is not recommended if all indoor units may require simultaneous continuous operation at full efficiency.
24K + 24K
18K + 18K + 18K
9K + 18K + 24K
9K + 21K + 21K
9K + 21K + 24K
12K + 18K + 21K
12K + 18K + 24K
12K + 21K + 21K
12K + 12K + 24K
9K + 9K + 18K + 18K
9K + 12K + 12K + 18K
9K + 12K + 12K + 21K
12K + 12K + 12K + 18K
9K + 9K + 9K + 24K
9K + 9K + 12K + 21K
9K + 9K + 12K + 24K
12K + 12K + 12K + 12K
9K + 9K + 9K + 21K
9K + 9K + 9K + 9K + 18K
9K + 9K + 9K + 12K + 12K
9K + 9K + 12K + 12K + 12K
9K + 9K + 9K + 9K + 12K
