Step 7: Remove evaporator components
Remove the screws as shown by the arrow in the graph
with a screwdriver.
(There are six (6) screws on the left and right of the
evaporator and five (5) on the evaporator outlet press
plates)
Step 8: Remove the fan plate subassembly
Remove the screws (as shown in diagram) with a
screwdriver to remove the plate that holds the air sweeping
fans in place.
