A01350693 Rev:P ECO: 7476 Date: 04/14/08 46
Symptom 11: The 135DE Exit Panel is beeping at one second intervals when a monitored resident is
within range of the door and the lock will NOT lock.
Potential causes and corrective actions:
• There may be a problem with the fire alarm relay in the fire alarm control panel. Verify that the 135DE
Exit Panel is connected to the proper fire alarm relay NO or NC.
• The Fire alarm system has been activated into an alarm condition. Remove the fire alarm wire from the
135DE Exit Panel. The beeping should stop. If the beeping continues, replace the 135DE Exit Panel. If
the beeping stops, replace the fire alarm wire.
•
If multiple Exit Panels are connected to an individual fire alarm relay, all panels must be turned on and wire
polarity must be identical on all panel connections
.
Symptom 12
: The 135DE Exit Panel does not release the lock when the fire alarm system is activated.
Potential causes and corrective actions:
• The fire alarm relay is not connected or not working properly.
• There is a possible open circuit in the fire alarm interface. Disconnect the fire alarm wire from the fire
alarm relay and the 135DE Exit Panel. Test the cable for an open circuit. If no open is found, test the fire
alarm test the fire alarm interface on the 135DE Exit Panel. Provide a short on the panel interface input.
The door should release and the Exit panel should beep.
• Verify that the 135DE Exit Panel is programmed for the proper fire alarm relay, NO or NC.
Symptom 13: The Remote Keypad with the 135DE Exit Panel does not work. (All functions of the 135DE
integrated keypad work properly.
Potential causes and corrective actions:
• Verify proper wiring and connections to the Remote Keypad from the Exit Panel.
• Reverse the connection of the ribbon cable on the Remote Keypad.
• There may be a broken or shorted keypad connector. Inspect the connector on the Remote Keypad and
the 135DE Exit Panel.
• There may be a broken or loose conductor in the ribbon cable. Test each conductor for continuity.
• There may be a bad Remote Keypad button. Replace the Keypad.
Symptom 14: The 135DE Exit Panel does not lock out the elevator when the Exit Panel is in alarm and the
elevator door is open.
Potential causes and corrective actions:
• Verify that wiring to the elevator control is connected in the Exit Panel.
• Remove the wire from the elevator interface connectors, Test for open and close. The relay should be open with
no alarm present and closed when there is an alarm present.
• If the relay tests OK, the problem is within the wire run to the elevator controls or in the elevator contols.
• If the relay does not work properly, replace the 135DE Exit Panel.
Symptom 15
: The 135DE Exit Panel is operating properly but the PM program does not seem to be
working, The Exit Panel does not arm at the programmed time.
Potential causes and corrective actions:
• The Exit panel programming has been initialized and all memory has been erased. Reprogram and enable this
feature.
• The Exit Panel programming has been turned off. Refer to the programming section in this manual to enable
this feature.
• The Exit Panel has been programmed incorrectly. Reprogram for the correct times.
• Reprogram the Exit Panel for change in Daylight Savings Time.
SECTION 12 TROUBLESHOOTING
