Seg WI Series User Manual

Setting of the Pickup Current of Phase Overcurrent Protection Stage I>>
WIC1‑2: DIP switch block 3, switches 1…4
WIC1‑3: HEX switch 5
This is the setting for the pickup current of the short-circuit element I>>.
The pickup currents in this table are given in units of the rated CT current In. (╚═▷ “11.1.3
Setting of the Rated CT current In”)
Pickup
»I>> . I«
(as a multiple of In)
HEX 5 DIP 3-1 DIP 3-2 DIP 3-3 DIP 3-4
1 0 OFF OFF OFF OFF
2 1 ON OFF OFF OFF
3 2 OFF ON OFF OFF
4 3 ON ON OFF OFF
5 4 OFF OFF ON OFF
6 5 ON OFF ON OFF
7 6 OFF ON ON OFF
8 7 ON ON ON OFF
9 8 OFF OFF OFF ON
10 9 ON OFF OFF ON
12 A OFF ON OFF ON
14 B ON ON OFF ON
16 C OFF OFF ON ON
18 D ON OFF ON ON
20 E OFF ON ON ON
This setting deactivates the
protection stage.
F ON ON ON ON
263WIC1WIC1-1.0-EN-MAN
