Setting of the Tripping Delay of Phase Overcurrent Protection Stage I>>
WIC1‑2: DIP switch block 3, switches 5…8
WIC1‑3: HEX switch 6
This is the setting for the tripping delay of the short-circuit protection »I>>« in seconds.
Tripping Delay
»I>> . t«
in seconds
HEX 6 DIP 3-5 DIP 3-6 DIP 3-7 DIP 3-8
0.04 0 OFF OFF OFF OFF
0.07 1 ON OFF OFF OFF
0.1 2 OFF ON OFF OFF
0.15 3 ON ON OFF OFF
0.2 4 OFF OFF ON OFF
0.25 5 ON OFF ON OFF
0.3 6 OFF ON ON OFF
0.4 7 ON ON ON OFF
0.6 8 OFF OFF OFF ON
0.8 9 ON OFF OFF ON
1.0 A OFF ON OFF ON
1.4 B ON ON OFF ON
1.8 C OFF OFF ON ON
2.2 D ON OFF ON ON
2.6 E OFF ON ON ON
3.0 F ON ON ON ON
264 WIC1 WIC1-1.0-EN-MAN
11 Appendix
11.1.4 Phase Overcurrent Protection – Settings via DIP Switches (WIC1‑2) or via HEX Switches (WIC1‑3)
