Threshold »IH2 / IH1«
WIC1‑2: DIP switch block 5, switches 5…8
WIC1‑3: HEX switch 10
The »IH2 / IH1« values are percentages, that specify the ratio of the 2
nd
harmonic to the
1
st
harmonic.
Related setting via DiggiMEC or via Smart view:
• [Protection Para / IH2] »IH2 . IH2 / IH1«,•
see ╚═▷ “4.4.2.1 Inrush – Settings via DiggiMEC or via Smart view”,
Threshold »IH2 / IH1« HEX 10 DIP 5-5 DIP 5-6 DIP 5-7 DIP 5-8
15.0 0 OFF OFF OFF OFF
16.0 1 ON OFF OFF OFF
17.0 2 OFF ON OFF OFF
18.0 3 ON ON OFF OFF
20.0 4 OFF OFF ON OFF
22.0 5 ON OFF ON OFF
24.0 6 OFF ON ON OFF
26.0 7 ON ON ON OFF
28.0 8 OFF OFF OFF ON
30.0 9 ON OFF OFF ON
32.0 A OFF ON OFF ON
34.0 B ON ON OFF ON
36.0 C OFF OFF ON ON
38.0 D ON OFF ON ON
40.0 E OFF ON ON ON
This setting deactivates the
Inrush Blocking.
F ON ON ON ON
268 WIC1 WIC1-1.0-EN-MAN
11 Appendix
11.1.6 Inrush – Settings via DIP Switches (WIC1‑2) or via HEX Switches (WIC1‑3)
