Seg WI Series User Manual

Threshold »Imax«
WIC1‑2: DIP switch block 6, switches 1…4
WIC1‑3: HEX switch 11
The Inrush threshold current »Imax« in this table is given in units of the rated CT current In.
(╚═▷ “11.1.3 Setting of the Rated CT current In”)
Related setting via DiggiMEC or via Smart view:
• [Protection Para / IH2] »IH2 . Imax«,•
see ╚═▷ “4.4.2.1 Inrush – Settings via DiggiMEC or via Smart view”.
Threshold »Imax«
(as a multiple of In)
HEX 11 DIP 6-1 DIP 6-2 DIP 6-3 DIP 6-4
2.0 0 OFF OFF OFF OFF
3.0 1 ON OFF OFF OFF
4.0 2 OFF ON OFF OFF
5.0 3 ON ON OFF OFF
6.0 4 OFF OFF ON OFF
7.0 5 ON OFF ON OFF
8.0 6 OFF ON ON OFF
9.0 7 ON ON ON OFF
10.0 8 OFF OFF OFF ON
11.0 9 ON OFF OFF ON
12.0 A OFF ON OFF ON
13.0 B ON ON OFF ON
14.0 C OFF OFF ON ON
15.0 D ON OFF ON ON
18.0 E OFF ON ON ON
20.0 F ON ON ON ON
269WIC1WIC1-1.0-EN-MAN
11 Appendix
11.1.6 Inrush – Settings via DIP Switches (WIC1‑2) or via HEX Switches (WIC1‑3)
