NOTICE!
The green “System/Ready” LED has the 󰊟xed (non-con󰊟gurable) meaning: “Ready to
Trip”.
This meaning is more strict than a simple “device is running”. Therefore it is possible (for
example if the WIC1 is solely supplied via DiggiMEC-USB) that the WIC1 is running, so
that you can con󰊟gure it and/or read out measuring values, but the “System/Ready” LED
is o󰈚 (e. g. because the 5 Volts of a USB interface are o.k. for the operation of the WIC1,
but do not su󰊡ce for the availability of a ~24 Volts trip pulse).
More details about the »System« LED(s) can be found in the table below, in ╚═▷ “6 Self-
Supervision” and in ╚═▷ “10 Troubleshooting”.
(WIC1 / DiggiMEC) System-LED: Built-in Signals WIC1
(Green)
System
Ready LED
WIC1
(Red)
System
Error LED
DiggiMEC
Two-Colored (Green+Red)
System LED
Device not ready (yet). This can also be the case if
the software has completely started, but the WIC1
has not (yet) collected enough electrical energy for a
trip pulse.
Or: The phase currents are not su󰊡cient for the WIC1
so that it is still switched o󰊞.
Or: The device has been restarted into the “Service
Mode” operating mode. In this mode, it is possible to
reset all settings to the factory defaults, or to install a
󰊟rmware update.
(Further Infos on the “Service Mode”: ╚═▷ “3.9.1.2
Special Keys During Power-on”)
OFF OFF OFF
WIC1 has completely booted, the protection functions
are running and there is enough electrical energy for
a trip pulse.
Constant
Green
OFF Constant Green
Green LED: as above i. e. the WIC1 has collected
enough electrical energy for a trip pulse.
Blinking red color: The WIC1 has done an automatic
restart (due to a device-internal error) and entered
a “Protection-Only” operating mode. In this mode,
only the protection and supervision functions have
been started. (This might hopefully reduce the risk of
another error.)
•
In particular, all communication functions are
•
inactive, including connections with DiggiMEC
and Smart view.
• The DiggiMEC 󰊠ag indicators / output relays,•
however, should be functional.
• Although the protection functionality is fully•
active it is recommended to check (and/or
replace) the WIC1.
OFF, or
Constant
Green
Blinking red Blinking Red, or
Blinking Red ↔ Green
A serious error has been detected, so that the WIC1
could not start as normal, but at least the (hardware-
based) backup protection is up and running. (See
╚═▷ “4.13 Integrated Backup Phase Overcurrent
Protection”.)
OFF Constant
Red, or OFF
• Constant Red: if the•
DiggiMEC is connected to a
PC via USB (so that there is
an external power supply)
• OFF: without supply•
94 WIC1 WIC1-1.0-EN-MAN
3 Hardware
3.8.1 LEDs
