Sega Outrun 2 User Manual

90
Item Component Part Description QTY Component Reference
1 PTR-1110UK ASSY FRAMEWORK BLACK NEW 1
2 NOA-1200UK ASSY CRT COVER UK 1 ASSY CRT COVER UK
4 ORT-1400JUK ASSY FRONT PANEL PENT 1
5 CTA-1150UK ASSY CC BOX WW 1
6 ORT-4000UK ASSY ELEC 1
7 PTR-1750UK ASSY SERVICE DOOR (BLACK) 1
8 PTR-1801UK REAR HATCH (BLACK) 1
9 NOB-1001UK FRAME COVER UR R 1
10 NOB-1002UK FRAME COVER UR L 1
11 NOA-1003 ENDCAP R 1
12 NOA-1004 ENDCAP L 1
13 RTS-1010UK BILLBOARD HOLDER 1
14 ORT-4100UK ASSY MAIN BD 1
15 ORT-1111UK SPACER FOR PENT MONITOR 4
18 ORT-1006UK SCR CAP 4
19 ORT-1710UK ASSY AC UNIT (BLACK PENT) 1
20 RTS-1116UK LID COMUNIPORT (BLACK) 1
21 ORT-20002UK ASSY CONTROL PANEL 1
23 PTR-1001UK CONTROL BOX 1
25 ORT-1014UK ENTRY COVER ORT 1
26 421-7501-17 STICKER FL 20W 1
27 837-13551-92 I/O CONTROL BD FOR JVS 1
28 LB1103 STICKER CAUTION 1 INSIDE CONTROL PANEL
(GEARS)
29 PTR-1005UK REAR COVER UPPER (BLACK) 1
30 NOA-1011 FL BRKT 1
33 ORT-1009UK STICKER SIDE L 1
34 ORT-1010UK STICKER SIDE R 1
35 RCR-1019 CHAIN HOLDER B 1
37 LB1102 STICKER DANGEROUS VOLTAGE 6 CRT,FL,HATCH,S/DOOR,CP,
R LOCK
38 LB1104 STICKER CAUTION, HOT SURFACE 1 FL COVER
40 CTA-4200UK ASSY XFMR 1
41 CTA-2007UK DRAINAGE GUTTER CE 1 -41
42 OS1177 TAPE D/S PVC 50mm X 50 M ROLL 0.5 -41
43 OS1239 SEALANT BLACK 0.1 -5
44 CTA-1011UK FOAM STRIP 8 X 6mm 0.75 -23
47 ORT-1001-AUK BRKT MTG MON REMOTE BD 1
101 200-3129-P ASSY CRT 29 31K PENT 1
102 390-5695-40-CUK FL TRAY 110V 40W (T12) 1
103 390-5695-40-DUK FL TUBE 40W 600L 1.5"DIA 1
