Sega Outrun 2 User Manual

91
Cont.
Item Component Part Description QTY Component Reference
105 280-A01248-PM ROUTER TWIST D12 SO4.8 PAN MED 9
106 280-A02048-PM ROUTER TWIST D20 SO4.8 PAN LG 7
107 280-A02000-A ROUTER TWIST D20 ADH 5
111 280-N02310-0B SLIT HARN WRAP 23mm DIA 1M BLK 0.2 WIRES THRU LH FRAME
HOLE
113 OS1008 CABLE TIE, NYLON 150mm 2
114 ORT-1117UK WATER GUARD CE PENT 1 AROUND MONITOR
CHASSIS
115 601-0460 CABLE TIE 100mm 10
116 OS1230 FOAM STRIP 2mm X 10mm 1.18 2 X 0.59m TO (8)
117 OS1220 FOAM STRIP 8mmSQ ADHESIVE 1 (21)-1
123 280-K00600-0B DRIVE FASTENER M6 BLACK 2 BASE BOX ABOVE COIN
DOOR
126 290093 CMS)TAPE,FOAM(BLK)-
3X6MMX25MTR
63
201 008-T00625-0C M6X25 TMP PRF TH CRM 14 (2)-6,(4)-4,(29)-4
202 030-000620-S M6X20 BLT W/S PAS 8 (5)-4,(23)-4
203 068-651616 M6 WSHR 16OD FLT PAS 8 (5)-4,(23)-4
204 010-P00408 M4X8 S-TITE PAN PAS 4 (6)-4
205 008-T00412-0C M4X12 TMP PRF TH CRM 14 (9)&(10)-5,(11)&(12)-2
206 050-F00600 M6 NUT FLG SER PAS 4 (101)-4
208 050-F00300 M3 NUT FLG SER PAS 8 (27)-4,(REMOTE BD)-2,(47)-2
209 032-000425 M4X25 W/BLT PAS 2 (14)-2
210 068-441616 M4 WSHR 16OD FLT PAS 2 (14)-2
211 008-B00825-0B M8X25 TMP PRF BH BLK 3 (21)-3
212 068-852216-0B M8 WSHR 22OD FLT BLK 3 (21)-3
213 050-F00500 M5 NUT FLG SER PAS 10 (21)-4,(EARTH)-6
215 000-P00416-W M4X16 MSCR PAN W/FS PAS 2 (4)-2
217 000-P00408-W M4X8 MSCR PAN W/FS PAS 7 (30)-4,(EARTHS)-3
221 000-P00512-W M5X12 MSCR PAN W/FS PAS 2 (35)-2
223 060-F00400 M4 WSHR FORM A FLT PAS 4 (6)-4
224 050-F00400 M4 NUT FLG SER PAS 6 (102)-2,(5E)-1,(29E)-1,(31E)-
1,(101)-1
225 068-652516 M6 WSHR 25OD FLT PAS 8 (40)-4,(101)-4
226 000-P00625 M6X25 MSCR PAN PAS 4 (40)-4
227 000-P00408 M4X8 MSCR PAN PAS 2 (103)-2
229 008-T00412-0B M4X12 TMP PRF TH BLK 18 (8)&(13)-4,(19)-6,(20)&(25)-2
230 068-441616-0B M4 WSHR 16OD FLT BLK 2 (25)-2
301 ORT-6001UK ASSY WIRE L 1
302 CTA-6002UK ASSY WIRE R 1
311 600-7159-070 WIRE HARN JVS PWR 070CM 1
321 CTA-60062 WIRE HARN I/O BOARD PWR 1
322 CTA-60066UK WIRE HARN SW UNIT EXT 1
323 CTA-60067UK WIRE HARN VOL EXT 1
324 CTA-60068UK WIRE HARN SPEAKER 1
