ASSEMBLY AND INSTALLATION
1
Move the product to the installation site. Hold the grips on the sides of the cabinet when moving it and
changing the direction it faces. Secure a 150 mm (5.9 in) space between the back wall and the back of the
cabinet for ventilation.
6
GRIP
150 mm (5.9 in)
2
Bring the adjusters into direct contact with the oor. Use a wrench to align the height of the adjusters until
the cabinet is perfectly level.
3
After setting, turn adjuster nuts upwards to tighten them and secure adjuster heights.
Tighten nut upwards.
150 mm (5.9 in)
Ensure that all of the
adjusters are in contact
with the oor.
Ensure that all of the
adjusters are in contact
with the oor.
5 mm (0.2 in)
ADJUSTER
