Sega Project DIVA Arcade Future Tone - Attaching the Flags

ASSEMBLY AND INSTALLATION
27
6-2 ATTACHING THE FLAGS
FLAG L
FLAG R
VISUAL GUIDE TO COMPLETED ATTACHMENT OF FLAGS
1
Remove 2 truss screws and take the pole lid off.
6
M4 x 8
POLE LID
TRUSS SCREW (2), black
2
Slide the supplied ag L onto the pole so that the design faces forward.
Slide the supplied ag L
onto the pole.
POLE
FLAG L
